| Model | GBP-L Series |
| Style | Wheel Type |
| Cell | REPT、EVE、etc |
| Cycle | 6000+ times |
| Life | 10 years |
| Certificate | CE 、MSDS、UN38.3 |
| Model | GBP48-280L | GBP48-314L | GBP48-560L | GBP48-628L | GBP512-280L | GBP51.2-314L | GBP51.2-560L | GBP512-628L |
| Nominal Voltage (V) | 48 | 51.2 | ||||||
| Cell Specification | 280 | 314 | 280 | 314 | 280 | 314 | 280 | 314 |
| Nominal Capacity (Ah) | 280 | 314 | 560 | 628 | 280 | 314 | 560 | 628 |
| Operating Voltage Range (V) | 42~54.75 | 44.8~58.4 | ||||||
| Recommended Charging Voltage (V) | 51.75 | 55.2 | ||||||
| Recommended Discharge Cut-off Voltage (V) | 45 | 48 | ||||||
| Standard Charge/ Discharge Current (A) | 100 | 100 | 100 | 100 | ||||
| Maximum Continuous Charge/Discharge Current (A) | 150 | 200 | 150 | 200 | ||||
| Operating Temperature (C) | -30~60(Recommended 10~35) | |||||||
| Allowable Humidity Range(%RH) | <85 | |||||||
| Storage Temperature(C) | -20~65(Recommended 10~35) | |||||||
| Charging Temperature(C) | 0~55 | |||||||
| Discharging Temperature(C) | 1-10~55 | |||||||
| Protection Level | IP20 | |||||||
| Cooling Method | Natural Air Cooling | |||||||
| Cycle Life | 5000+ Times at 80% DOD | |||||||
| Maximum Dimension (D*W*H)mm | 248*680*880 | 890*350*1060 | 248*680*880 | 890*350*1060 | ||||
| Weight(kg) | 137 | 141 | 280 | 289 | 139 | 144 | 284/293 | |
| Note: The above data is for reference only. in case of any changes, no further notice will be given. For special customization requirements, please consult with the engineer. | ||||||||
