| Model | GLV1 Series |
| Style | Stackable |
| Cell | REPT、EVE、etc |
| Cycle | 6000+ times |
| Life | 10 years |
| Certificate | CE 、MSDS、UN38.3 |
| Model | GLV1-P10 | GLV1-P15 | GLV1-P20 | GLV2-P20 | GLV2-P30 | GLV2-P40 |
| Battery Module Model | LFP48V/100Ah | LFP48V/200Ah | ||||
| Battery Module Nominal Energy(kWh) | 4.8 | 9.6 | ||||
| Rated Voltage(V) | 48 | |||||
| Number of Cell Modules in Single Cluster | 2 | 3 | 2 | 3 | 4 | |
| Single Cluster Battery Energy (kWh) | 9.6 | 14.4 | 19.2 | 19.2 | 28.8 | 38.4 |
| Maximum number of clusters in parallel | 8 | |||||
| Operating voltage range(V) | 42~54.75 | |||||
| Recommended Charge Voltage(V) | 51.75 | |||||
| Recommended discharge cut-offvoltage(V) | 45 | |||||
| Maximum charge/discharge current(A) | 0.5C | |||||
| Unit cluster size (D*W*H)mm | 425*700*672 | 425*700*864 | 425*700*1056 | 479*700*848 | 479*700*1128 | 479*700*1408 |
| Unit duster weight(kg) | 145 | 199 | 254 | 228 | 324 | 420 |
| Communication mode | CAN/485/Bluetooth | |||||
| Proper temperature(C) | -30~60(Recommended10~35) | |||||
| Storage temperature(C) | -20~65(Recommended10~35) | |||||
| Humidity(%RH) | <85 | |||||
| Protection level | IP20 | |||||
| Cooling method | Natural Air Cooling | |||||
| Note: The above data is subject to change without prior notice. | ||||||
